tinySA Ultra+ ZS407 – Handheld Spectrum Analyzer & Signal Generator

$320.00

A compact, versatile handheld device that combines a full-featured spectrum analyzer and signal generator in one portable unit. Designed for hobbyists, engineers, and RF technicians, the tinySA Ultra+ provides professional-grade diagnostic capabilities at an affordable price. With an ultra-wide frequency range up to 7.3 GHz, it is ideal for analyzing signals from HF through modern wireless bands

Quantity

In Stock

Security policy (edit with Customer reassurance module)

Delivery policy (edit with Customer reassurance module)

Return policy (edit with Customer reassurance module)

Key Features

Ultra-Wide Frequency Range: Covers 100 kHz to 900 MHz in normal mode, and up to 7.3 GHz in Ultra mode, with the ability to observe signals up to 12 GHz using harmonic tracking .

Built-in Signal Generator: Functions as a sine wave generator (0.1 – 900 MHz) or square wave generator (up to 6.3 GHz), perfect for filter and circuit testing .

Large Touchscreen Display: 4-inch color TFT display (480×320 pixels) showing up to 450 scan points with resistive touch control .

Long Battery Life: 5000 mAh rechargeable battery provides over 3 hours of continuous operation – ideal for fieldwork .

Low Noise Amplifier (LNA): Switchable 20 dB internal LNA for improved weak signal reception up to 7.3 GHz .

Onboard Storage: MicroSD card slot (32 GB card included) for saving measurements, settings, and screen captures .

High Accuracy: Low phase noise down to -100 dBc/Hz, with ±2 dB power level accuracy after calibration .

Additional Outputs: 3.5mm headphone jack for audio demodulation (AM) and USB-C port for charging and PC control .

Key Technical Specifications

Specification Value

Frequency Range (Analyzer) 100 kHz – 900 MHz (Normal), up to 7.3 GHz (Ultra)

Frequency Range (Generator) Sine: 100 kHz – 900 MHz, Square: up to 6.3 GHz

RBW Filters 200 Hz – 850 kHz (switchable)

Scan Points Up to 450 points
